cattle panels nz

A TOP range cattle panel, a superior heavy-duty panel that is built from 50mm x 50mm uprights and 1.6mm thick, with 5 ovals 120mm x 30mm and 1.8mm thick, comes with pins and brackets to lock the panels together, metal-capped to keep the rain out, and bottom plate to make sure you can secure them to the ground. This product is sturdy and reliable, and there is no fear that the structure will collapse. It is made from the highest quality of galvanized steel and chain link mesh. Our standard galvanized cattle panel has six rails and is 2.1m long and 1.8m high. We can also manufacture cattle panels to customer length or height.

Features

HDG surface supplies high corrosion resistance performance for several years. Strong and rigid structure withstand heavy impact from horses. No sharp edges to protect horses from being hurt. Quick pin structure for easy installation and dismantle. 1.8 meter standard height and various customized sizes.

Packing terms:

Cattle Fence panel: plastic film +metal pallet

Cattle Fence Accessory: small plastic bag + carton box.

Why choose us?

1. All of our goods will pass a quality inspection before shipping them out.

2. Best after-sale service, a customer can follow their order situation, no matter production line, wSheepuse or shipment.

3. More than 6 years of experience in export to handle your order more smoothly.

4. Less than one container loading is accepted.

5. On-time delivery, in general, 20-30 days.

6. Multimode payment, L/C, T/T, etc.

7. Special dimension is available according to your request.

Advantages of Cattle Panel

Our cattle panel with many advantages list as the following

1. Portable: easy, fast to handle (sheep, remove and put down), makes the fence panel very flexible.

2. Robust: the interlocking system makes the fence very stable; quality steel and fully welding make

the panel stronger; heavy-duty and anti-broken; high zinc or PVC coated to make the fence

durable.

3. Environment Protection: connection with welded bracket lugs and joining pins; no need to dig

holes or lay foundations. And it benefits grassland protection.

4. Livestock Protection: no sharp edge, very smooth welding spot finished

5. Cost-effective: give your corral years of service and minimal maintenance at a low initial cost

Details

A cattle yard panel is usually called a cattle panel, horse panel, livestock panel, corral panel, etc.

It is made with welded hot dip galvanized pipes for fencing livestock, such as cattle, cows, bulls, calves, Dairy sheep, goats, and dogs.

TopFencing supplies quality cattle panels, horse panels, Sheep panels, and custom-made panels suitable for all livestock.

All products are manufactured using high-quality pre-galvanized RHS & pipe.

A versatile cattle panel with rounded edges can be used as a cattle panel, horse panel or sheep panel.

Extra C and L lugs can be supplied to integrate panels into an existing yard.

Corrosion Form: hot-dipped galvanized or paint

Features: It can quickly and easily be installed without the need to disturb the surface area by digging holes or laying foundations.

Description of Cattle Yard Panel:

1. 1.8m high with 6 bars/rails or 1.6m high with 5 bars/rails.
2. Complete with Caps & Footplates.
3. Holes for the ground pin on one leg of each panel.
4. Elongated lug holes in brackets for ease when connecting.

Specification cattle panel

Material:	Q235 low carbon steel
Frame:	32mm OD,38mm OD,40mm OD etc
Size:	5ftx8ft,5ftx10ft,5ftx12ft,5ftx16ft etc
Corrosion Form：	galvanized steel and powder coated, hot dipped galvanized
Color:	green, black, blue, yellow, red etc
Features:	It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations.
Main markets:	Australia, European countries, America, Canada and Asia etc

Square Style Cattle Fence -- Popular for Horse: Customer requests can be reached.

Height x Length	1.8 x 2.1m ( 6 rails ); 1.6 x 2.1m ( 5 rails ); 1.8 x 3.0m
Vertical Pipe	40 x 40 x 1.6 /2.0mm; 50 x 50 x 1.6 /2.0mm
Horizontal Pipe	40 x 40 x 1.6 /2.0mm; 50 x 50 x 1.6 /2.0mm

Oval Style Cattle Fence -- Popular for Cow:Customer requests can be reached.

Height x Length	1.8 x 2.1m ( 6 rails ); 1.6 x 2.1m ( 5 rails ); 1.8 x 3.0m
Vertical Pipe	40 x 40 x 1.6 /2.0mm; 50 x 50 x 1.6 /2.0mm square pipes
Horizontal Pipe	60 x 30 x 1.6 /2.0mm; 80 x 40x 1.6 /2.0mm oval rails

Round Style Cattle Fence -- Popular for Horse:Customer requests can be reached.

Height x Length	1.8 x 2.1m ( 6 rails ); 1.6 x 2.1m ( 5 rails ); 1.8 x 3.0m
Vertical Pipe	32mm OD x 1.6 /2.0mm; 42mm OD x 1.6 /2.0mm
Horizontal Pipe	32mm OD x 1.6 /2.0mm; 42mm OD x 1.6 /2.0mm

Farm gate

Specification	Normal size
Height x Length	1.8m x 2.1m, 1.6 x 2.1m, 1.8m x 2.4m etc
pole style	Round pipe or square tube or oval tube
Pole specification	32mmO. D, 42mmO. D, RHS40mm, RHS50mm etc
Package details	In steel pallet or in bulk
